Product Details
Features
■The digital voice is clear and loud.
■Same-frequency forwarding, multi-level networking, wide signal coverage and cost saving.
■Frequency software programming, easy to use.
■Applicable to high-rise, basement and tunnel coverage.
■Support Type-C cable charging.
■Standard K-head interface.
■Digital format independent algorithm, never tandem, clear sound quality.
Suitable for a variety of scenarios
Construction sites, basements of high-rise buildings, tunnels, hotels, properties, KTV, office buildings, factories, forest fire prevention
Technical indicators
| General specifications | |||
| Frequency range | UHF：400-470MHz | ||
| Number of channels | 16 pcs | ||
| Channel spacing | 12.5KHz | ||
| Operating voltage | 7.4V | ||
| Battery as standard | 2600mAhLi-Ion | ||
| Battery standby | Long standby time of 70 hours | ||
| Frequency stability | Soil 1.0 PPM | ||
| Operating temperature range | -30℃~+50℃ | ||
| Antenna impedance | 50H | ||
| Dimensions | 127*57*40mm (H x W x D) (without antenna) | ||
| Weight (with antenna and battery) | 261g | ||
| transmitter | Receiver | ||
| Output power | UHF: 5W | Sensitivity (digital) | ≤0.22μV/BER5% |
| Modulation mode | 12.5 KHz data and voice 7K60FXW, data only 7K60FXD | Adjacent path selectivity | 60/70dB |
| Clutter and harmonics | -36dBm<1GHz -30dBm> 1GHz | Intermodulation | 65dB |
| Signal-to-noise ratio | 40/45dB | Spurious response suppression | 70dB |
| Audio distortion | ≤3% | Signal-to-noise ratio | 40/45dB |
| Modulation limits | Soil 2.5@12.5KHz; Earth 5.0@25KHz | Audio output power | 1W |
| Audio Response (300- 3000Hz) | +1 to -3 dB | Audio response | +1-~-3dB |
| Conducted emission spurious | < -57dBm | ||
Battery accessories
